KA3005D High Precision Adjustable Digital DC Power Supply 0~30V 0~5A COM31

Fr145,800

It has an easy to read 4 digit LED is used to display the voltage and current values and 4 programmable storage setting.This is a heavy duty single-channel, constant-voltage and constant-current Linear power supply with low ripple and noise, high reliability and high accuracy.The voltage and current are continuously adjustable.

9 in stock

SKU: 8650EQM Category:

Description

It has an easy to read 4 digit LED is used to display the voltage and current values and 4 programmable storage setting.This is a heavy duty single-channel, constant-voltage and constant-current Linear power supply with low ripple and noise, high reliability and high accuracy.The voltage and current are continuously adjustable.

Product Features

  • Compact Design
  • Dual 4 Digit LED Displays
  • Digital Controls
  • Output switch control
  • Switchable between 110v and 220v
  • 4 sets of parameters can be stored inside for fast recall
  • Keyboard Lock to prevent accidental changing of set parameters
  • Circuit protection for over load, short circuit and over temperature.
  • Automatic switching between mA and A display
  • Quiet variable speed fan

Description

Operating Conditions:

Input voltage:110V +/-10% switchable to 220V  +/-10%
Frequency range: 50- 60Hz
Operating temperature: 32-104 F  (0-40 ºC)
Operating humidity: < 80%RH
Storage temperature: 32-158 F  (0-70 ºC)
Storage humidity: < 70%RH

Stable Voltage:

Output Voltage Range: 0-30V Continuously adjustable
Setup Resolution: 10 mV
Setup Accuracy: <0.05% +20 mV
Ripple: < 1mVRMS
Read back Accuracy: 10 mV
Temp. Coefficient: < 100 ppm+5 mV
Read back Temp. Coefficient: < 100 ppm+5 mV
Stable Current:
 Output Current Range: 0-5A  Continuously adjustable
Setup Resolution: 1 mA
Setup Accuracy: <0.1% +3 mA
Ripple: < 3mARMS
Read back Accuracy: 1 mA
Temp. Coefficient: < 100 ppm+5 mA

Read back Temp. Coefficient: < 100 ppm+5 mA

Weight: 9.5 lbs. (4.3 Kg)
Dimensions: 4.3 x 6.1 x 10.25 inches  (110 x 156 x 260mm)
Includes: user’s manual, power cable and test leads
APPLICATION
It is designed for use in labs, colleges and in production.
